Advance Ply
Gold Marine
- Home
- Advance Ply Gold Marine
Available in
- 6mm
- 9mm
- 12mm
- 16mm
- 19mm
MADE WITH E1 GRADE RESIN, BOILING WATER PROOF, MARINE GRADE, IS:710, FULLY HARDWOOD CONSTRUCTION
Features
- E1 MPF MARINE Grade Resin
- IS: 710 Grade
- Boiling water resistance for >200hrs
- All Glue Line Treated with Anti Borer, Termite & Fungi Chemicals
- High Viscosity Resin Technology
Advantages
- Water proof grade bonding
- Marine grade plywood
- Long lasting bond even under high moisture or humidity
- Stops insects and fungus from attacking the plywood
- Helps even spreading of resin Leading to perfect bond between layers
Benefits
- Low in Emission, strong in Water Proofing
- Can be used in Exterior conditions or severe humid environments
- Very high water-proofing and longevity of products
- No powders formation decay or termite Attack on your furniture
- Uniform Bonding and Strength of plywood
Technical Specifcation for Marine Grade Plywood
Base Material
Hardwood
Face material
Tropical hardwood Species
Glue/Adhesion
Bonded with Phenol formaldehyde resin with provides boiling water proof
Calibrated
Yes
Compliance standard
Conforms to IS 710 (Indian standard for Marine plywood)
Thickness Range
Commonly available in 6 mm to 19 mm
Standard Size
Sheet typically comes in such as 8×4, 7×4, 6×4, 8×3, 7×3, 6×3
Density
Avg density – 0.75g/cm 3
water proof
Boiling water proof
Moisture Content
5 ~ 15% in oven dry method
Formaldehyde emission type
E1 Grade
CCB Treated
Core treated with Copper, Chrome, Boron
Weather Resistance
Withstand adverse climatic conditions
Screw holding capacity
More than 1600 N
Retention of Preservative
12.5kg/m3
Fire Resistance
Flame penetration – More than 60 min., Flammability – More than 45 min., Rate of burning – More than 30 min.
Modulus of Elasticity-Dry state
Along the grain – Avg – 6589 N/mm2, Min – 6036 N/mm2, Across the grain – Avg – 4890 N/mm2, Min – 4352 N/mm2
Modulus of rupture-Dry state
Along the grain – Avg – 49 N/mm2, Min – 43 N/mm2
